In the food processing industry, keeping the food fresh, tasty, and full of nutrition is always very important. With new technology, freezing methods are getting faster and more advanced. Today, the IQF Tunnel Freezer, especially the type that uses liquid nitrogen, is becoming a popular choice for food companies.
This article will help you understand what an IQF tunnel freezer is, how it works, its main advantages, where it is used, and how to choose the right one for your business.
IQF means Individual Quick Freezing. An IQF tunnel freezer is a machine used to freeze food very fast. It freezes each piece of food individually — for example, each strawberry, each shrimp, or each cube of meat — so they do not stick together.
Food moves through a closed tunnel on a conveyor belt. Inside the tunnel:
This keeps the food’s texture, freshness, and nutrition much better than slow freezing, which may take many hours and cause big ice crystals that damage cells.
Today, IQF tunnel freezers are widely used in frozen seafood, vegetables, meat, and ready meals.
The freezing process has three steps:
Step 1: Pre-processing
Food is cleaned, cut, or blanched before freezing.This helps remove dirt and keeps the food safe and fresh longer.
Step 2: Quick Freezing in the Tunnel (Main Step)
● Food enters the conveyor belt
● Liquid nitrogen spray creates −50°C to −100°C temperature around the food
● Food freezes very fast (about 3–10 minutes)
Liquid nitrogen has a boiling point of −196°C, so it removes heat instantly.This creates small ice crystals, protecting the food structure and preventing juice loss when thawing.
Step 3: Post-processing
Frozen food comes out loose and separated — easy for sorting and packing.Temperature sensors check that it reaches the safe level below −18°C.
Liquid nitrogen freezing does not need compressors, so it uses less power and is easy to maintain. It is also environmentally friendly.
| Advantage | Benefit |
| Better food quality | Keeps natural color, taste, texture, and nutrients |
| Fast and continuous production | High capacity, less labor, more efficiency |
| Works for many food types | Suitable for seafood, fruit, vegetables, meat, and more |
| Safe and hygienic | Stops bacteria growth and extends shelf life |
| Environment-friendly | Liquid nitrogen has no harmful emissions |
These advantages make IQF technology a strong tool for modern food business growth.
IQF tunnel freezers are used in many food categories:
These examples show that IQF helps companies upgrade their product quality and business value.
When planning to buy, consider:
| Key Factor | What to check |
| Food type and amount | How much do you freeze per hour? What shape and size? |
| Freezing performance | Belt speed, freezing temperature, energy use |
| Space and installation | Factory layout, liquid nitrogen supply |
| Supplier service | Training, spare parts, after-sales support |
| Total cost | Purchase + long-term running cost |
| Sustainability | Natural refrigerants and low energy use |
The IQF tunnel freezer represents the highest level of food freezing technology.It offers:
✔ Better food quality
✔ Faster production
✔ Lower waste
✔ Higher business value
Whether you process seafood, vegetables, meat, or ready meals, IQF freezing can upgrade your products and make your business stand out. As a professional supplier of liquid nitrogen freezing systems, SPEEDCRYO provides customized IQF solutions to help you succeed in the global food market.
